| Model |
IPC86CEB-AF18KC-I0 |
| Ürün Tipi |
12MP OmniView Fixed IR Fisheye Network Camera |
| Maksimum Çözünürlük |
12 MP |
| Sensör |
1/1.7" CMOS |
| Minimum Aydınlatma |
Color: 0.03 Lux (F2.0, AGC ON), IR ile 0 Lux |
| Gündüz / Gece |
IR-cut filter with auto switch (ICR) |
| Shutter |
Auto / Manual, 1 ~ 1/100000 s |
| S/N |
> 52 dB |
| WDR |
DWDR |
| Lens |
1.8 mm sabit fisheye lens, F2.0 |
| Görüş Açısı |
Yatay: 180°, Dikey: 180°, Diyagonal: 180° |
| DORI Mesafeleri |
Detect: 43.8 m, Observe: 17.5 m, Recognize: 8.8 m, Identify: 4.4 m |
| IR Aydınlatma |
360° fill-in light, 15 m IR mesafe, 850 nm, Auto / Manual kontrol |
| Video Sıkıştırma |
Ultra 265, H.265, H.264, MJPEG |
| Ana Akış |
Fisheye View: 12 MP (4000 × 3000)@20 fps; 3000 × 3000@20 fps; 2560 × 2560@25 fps. Panorama View: 12 MP (4000 × 3000)@20 fps; 3000 × 2000@20/25 fps; 3000 × 1500@20/25 fps. PTZ View: 1920 × 1080@20/25 fps |
| Alt / Üçüncü Akış |
Sub Stream: 2000 × 1500@20 fps; 2000 × 2000@25 fps. Third Stream: D1 @20/25 fps; CIF @20/25 fps |
| Video Bit Rate |
128 Kbps ~ 16 Mbps |
| Akış Özellikleri |
Triple streams, U-code, OSD (8’e kadar), Privacy Mask (4 alana kadar), ROI |
| Çözümleme Modları |
Donanımsal ve yazılımsal çoklu panorama / PTZ / fisheye görüntüleme modları |
| Görüntü İyileştirme |
White Balance, 2D/3D DNR, Smart IR, BLC, Digital Defog, Flip seçenekleri |
| Akıllı Fonksiyonlar |
Cross line detection, intrusion detection, heat map (management platform ile), motion detection, tampering alarm, audio detection |
| Ses |
G.711U, G.711A, 64 Kbps, 8 kHz, built-in dual-mic, built-in speaker, two-way audio desteği |
| Depolama |
MicroSD, maksimum 512 GB; Network Storage: ANR, NAS (NFS) |
| Protokoller |
IPv4, IPv6, IGMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS |
| Entegrasyon |
ONVIF (Profile S, Profile G, Profile T, Profile M), API, SDK |
| Kullanıcı / Host |
32 kullanıcıya kadar, 3 seviye: administrator, common user, operator |
| Güvenlik |
Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, TLS 1.2, WSSE, Basic ve Digest Authentication |
| Arayüzler |
Audio I/O: 1 input / 1 output, Alarm I/O: 2/1, 1 × RS485, 1 × RJ45, 1 BNC video output |
| Web Tarayıcı |
Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+ |
| Koruma |
IP67 (IEC 60529), IK10 (IEC 62262) |
| Besleme |
DC 12 V±25%, PoE (IEEE 802.3af) |
| Maksimum Güç Tüketimi |
12.0 W |
| Boyutlar |
Ø149 mm × 55 mm |
| Ağırlık |
0.524 kg |
| Malzeme |
Metal + Plastic |
| Çalışma / Depolama Ortamı |
-30 ℃ ~ 60 ℃, Nem: ≤ 95% RH (yoğuşmasız) |
| Surge Protection |
4 KV |
| Reset Butonu |
Support |
| Web Client Language |
20 Dil: Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese |
